Créer des API robustes et flexibles avec GraphQL

Version imprimable, PDF et e-mail

API design is an area where there can be a lot of contention between client application developers and backend developers. REST APIs enabled us to design stateless servers and structured access to resources for over two decades, and it continues to serve the industry, mainly due to its simplicity and moderate learning curve.

REST was developed around the year 2000 when client applications were relatively simple and the development pace was not as fast as it is today.

With a traditional REST-based approach, the design would be based on the concept of resources a given server manages. Then, we would typically rely on HTTP verbs such as GET, POST, PATCH, DELETE to perform CRUD operations on those resources.

Since the 2000s, several things have changed:

  • Increased usage of single-page applications and mobile applications created a need for efficient data loading.
  • Many of the backend architectures have turned from monolithic to µservice architectures for faster and more efficient development cycles.
  • A variety of clients and consumers are needed for APIs. REST makes it hard to build an API that supports multiple clients, as it would return a fixed data structure.
  • Businesses expect to rollout features faster to the market. If a change needs to be done on the client-side, it often requires a server-side adjustment with REST, leading to slower development cycles.
  • Increased attention on user experience often leads to designing views/widgets that need data from multiple REST API resource servers to render them.

GraphQL as an alternative to REST

GraphQL is a modern alternative to REST that aims to solve several shortcomings, and its architecture and tooling are built to offer solutions for contemporary software development practices. It allows clients to specify exactly what data is needed and allows fetching data from multiple resources in a single request. It works more like RPC, with named queries and mutations instead of standard HTTP-based mandatory actions. This puts control where it belongs, with the backend API developer specifying what is possible, and the client/API consumer specifying what is required.

Here is a sample GraphQL query, which was an eye-opener for me when I first came across this. Assume that we are building a microblogging website, and then we need to query for 50 recent posts.

query {

recentPosts(count: 50, offset: 0) { id

title

tags

content author {

id

name profile {

email interests

}

}

}

}

The above one GraphQL query aims to request:

  • Recent 50 posts
  • Id, title, tags, and content for each blog post
  • Author information containing id, name, and profile information.

If we have to use a traditional REST API approach for this, the client would need to make 51 requests. If posts and authors are considered separate resources, that’s one request for getting 50 recent posts and then 50 requests for getting author information for each post. If author information can be included in the post details, then this could be one request with REST API as well. But, in most cases, when we model our data using relational database normalization best practices, we would manage author information in a separate table, and that leads author information to be a separate REST API resource.

Here's the cool part with GraphQL. Say in a mobile view, we don't have real estate on screen to show both the post content and author profile information. That query could now be:

query {

recentPosts(count: 50, offset: 0) { id

title

tags

author {

id

name

}

}

}

The mobile client now specifies the information it desires, and GraphQL API provides the exact data it’s asked for, nothing more and nothing less. We didn't have to make any server-side adjustments, nor did our client-side code have to change significantly, and our network traffic between client and server is optimal.

The point to note here is that GraphQL lets us design flexible APIs based on client-side requirements rather than from a server-side resource management perspective. A general perception is GraphQL makes sense only for complex architectures involving several dozens of µservices. This is true to some extent, given that there is some learning curve with GraphQL compared to REST API architectures. But, that gap is closing, with significant intellectual and financial investment from the emerging vendor-neutral foundation.

Barracuda is an early adopter of GraphQL architectures. If this blog has piqued your interests, please follow this space for my subsequent blogs where I will delve into more technical details and architectural benefits.
